ULTRAOX VSA plants give industry its own on-site oxygen production, with large continuous flows, especially for low pressure applications. The system delivers oxygen at a concentration between 75% and 95% at 50 kPa. Higher pressures can be achieved with an additional oxygen booster as part of the supply, on demand.
On-site production gives total autonomy for the use and production of oxygen in your own plant.
Can replace existing oxygen cryogenic systems with liquid oxygen tanks, or work as the main source of supply.
Few parts to service, with large service intervals.
Life cycle calculated for 150,000 hours (20 years), on a skid or container system for easy connection.
| Model | Flow at 90% m³/h | Flow at 90% kg/h | Flow at 93% m³/h | Flow at 93% kg/h | Energy at 90%, 50 kPa, kW | Energy at 90%, 800 kPa, kW |
|---|---|---|---|---|---|---|
| ULTRAOX VSA 180 | 22 | 15.4 | 18 | 12.6 | 9 | 12 |
| ULTRAOX VSA 300 | 42 | 29.4 | 30 | 21 | 18 | 22 |
| ULTRAOX VSA 600 | 72 | 50.4 | 60 | 42 | 30 | 40 |
| ULTRAOX VSA 900 | 108 | 75.6 | 90 | 63 | 45 | 60 |
| ULTRAOX VSA 1200 | 144 | 100 | 120 | 84 | 60 | 75 |
| ULTRAOX VSA 1800 | 216 | 151 | 180 | 126 | 90 | 120 |
| ULTRAOX VSA 2400 | 288 | 201 | 240 | 168 | 120 | 150 |
Performance data based on standard cubic metre, 15 °C, 1 atmosphere, 40% RH. Energy consumption data ± 5%. Purity data can vary up to 2%. Other capacities available on request.
Oxygen at a concentration between 75% and 95% at 50 kPa. Higher pressures can be achieved with an additional oxygen booster, on demand.
No. ULTRAOX VSA is an industrial line. For medical oxygen, see ULTRAOX ST and ULTRAOX SC.
Aquaculture, wastewater treatment plants, hydrogen sulphide (H₂S) reduction processes, gold leaching in mines, bleaching of pulp and industrial furnaces.
Yes. It can replace existing oxygen cryogenic systems with liquid oxygen tanks, or work as the main source of supply.
Seven models, ULTRAOX VSA 180 to 2400, from 22 to 288 m³/h at 90%. Other capacities are available on request.
