ULTRAOX SC Oil-Free PSA Medical Oxygen Plant

Q: Is ULTRAOX SC oil-free?

The air compressors are. ULTRAOX SC uses ULTRACECO SC oil-free scroll compressors. ULTRAOX ST uses ULTRASCREW oil lubricated screw compressors.

Q: What purity does it deliver?

93% ± 3%, conforming to European Pharmacopoeia (Ph. Eur.) and United States Pharmacopeia (USP) specifications for medical oxygen.

Q: What capacity range is available?

16 models, from 3.10 Nm³/h on ULTRAOX 30 to 165.3 Nm³/h on ULTRAOX 1640.

Q: What happens if purity drops?

An alarm is raised at 90% purity. If purity falls below 90%, the oxygen flow is shut off and purged.

Q: What are the air and oxygen pressures?

Air inlet > 7.5 bar and oxygen outlet 5 to 6 bar.

16plant models, ULTRAOX 30 to 1640

3.10 to 165.3Nm³/h of oxygen

93% ± 3%oxygen purity

Get the highlights.

The ULTRAOX SC plant produces medical oxygen at 93% ± 3% purity from compressed air, with ULTRACECO SC oil-free scroll compressors and an ULTRACON PSA generator. It is Medical CE marked (CE 1639) under Directive 93/42/EEC and compliant with EN ISO 7396-1 (Medical gas pipeline systems).

Oil-free scroll compression

ULTRACECO SC oil-free scroll air compressors, with belt drive for easier maintenance and automatic start-stop sequencing.

Purity under control

An ULTRACON dual-column PSA generator delivers continuous flow. Alarm threshold at 90% purity, with oxygen flow shut off and purge if purity falls below 90%.

Sized to the site

Factory integration and site-specific sizing take local climate and installation conditions into account, in three altitude bands up to 3,000 m.

Filtered oxygen

Precision media captures particles down to 0.01 µm, with autoclave-sterilisable media, integrity-tested to exceed HTM 02-01 (Medical gas pipeline systems).

Find your size.

Type the oxygen flow you need. We show the smallest ULTRAOX SC in the datasheet that delivers it.

01 Oxygen flow needed

Nm³/h

Technical specifications.

Oxygen production capacity: 3.10 to 165.3 Nm³/h
Max. oxygen purity: 93% ± 3%, per Ph. Eur.
Compressor: ULTRACECO SC oil-free scroll, belt drive, automatic start-stop sequencing. TEFC Class F motor with shaft-mounted fan, intake air filter, relief valve and non-return protection, cyclonic separator with electronic drain. Altitude bands 0 to 1,000 m, 1,000 to 2,000 m and 2,000 to 3,000 m
Air treatment: ULTRACOOL aftercooler, fully air-cooled, cooling delta about 10 °C above ambient. CTA chain (FF/MF/SMF/AK), solid particles < 0.01 µm
Refrigeration dryer: ULTRASEC. Dew point +2 °C @ 7 barg, max inlet pressure 14 barg, max inlet temperature 70 °C, max ambient temperature 55 °C, refrigerant R513A (GWP 613)
Air receiver: Hot-dip galvanised carbon steel, vertical, PED 2014/68/EU (Pressure Equipment Directive). Max operating pressure 11 or 11.5 bar by size, test pressure 15 bar
Oxygen generator: ULTRACON, dual-column PSA cycle. Air inlet > 7.5 bar, oxygen outlet 5 to 6 bar, oxygen dew point -50 °C
Oxygen tanks: Process tank and storage tank, vertical, with medical-grade lining on the process tank. PED 2014/68/EU (Pressure Equipment Directive) and EN 286 (simple unfired pressure vessels). Test pressure 15 bar
Oxygen filtration: Precision media captures particles down to 0.01 µm, autoclave-sterilisable media, integrity-tested to exceed HTM 02-01 (Health Technical Memorandum 02-01: Medical gas pipeline systems)
Control and alarms: Siemens touch screen PLC with HD interface. Oxygen purity and outlet pressure with trend curves, instantaneous flow and total production. Alarm threshold at 90% purity, oxygen flow shut off and purge if purity < 90%
Power supply: 400 V / 50 Hz / 3 AC, control voltage 230 V / 50 Hz / 1 AC. Ambient temperature +5 °C to +45 °C
Certification: Medical CE marked (CE 1639) under Directive 93/42/EEC
Standards: EN ISO 7396-1 (Medical gas pipeline systems, Part 1: Pipeline systems for compressed medical gases and vacuum). Conforms to European Pharmacopoeia (Ph. Eur.) and United States Pharmacopeia (USP) specifications for medical oxygen. Quality system ISO 13485 (Medical devices: quality management systems)
Country of origin: PT (EU)

ULTRAOX SC models

Model	Oxygen Nm³/h	Max. daily filling capacity, cylinders (50 L @ 150 bar)	Oxygen generator
ULTRAOX 30	3.10	10	ULTRACON 4
ULTRAOX 50	4.60	14	ULTRACON 5
ULTRAOX 70	6.50	20	ULTRACON 6
ULTRAOX 90	8.00	25	ULTRACON 7
ULTRAOX 100	9.50	30	ULTRACON 8
ULTRAOX 120	12.4	40	ULTRACON 9
ULTRAOX 180	18.2	58	ULTRACON 10
ULTRAOX 260	26.2	84	ULTRACON 11
ULTRAOX 370	36.5	116	ULTRACON 12
ULTRAOX 440	43.5	139	ULTRACON 13
ULTRAOX 520	52.4	168	ULTRACON 11 × 2
ULTRAOX 560	55.7	178	ULTRACON 14
ULTRAOX 730	73.0	232	ULTRACON 12 × 2
ULTRAOX 820	82.7	264	ULTRACON 15
ULTRAOX 1120	111.4	356	ULTRACON 14 × 2
ULTRAOX 1640	165.3	528	ULTRACON 15 × 2

Simplex layout. Same oxygen capacity in all three altitude bands.

ULTRAOX SC components per model

Model	Aftercooler	Air treatment	Refrigeration dryer	Air receiver	Oxygen process tank	Oxygen storage tank
ULTRAOX 30	ULTRACOOL 1	CTA 13	ULTRASEC 6	270 L, 11 bar	100 L, 11 bar	200 L, 11 bar
ULTRAOX 50	ULTRACOOL 1	CTA 13	ULTRASEC 7	500 L, 11 bar	100 L, 11 bar	200 L, 11 bar
ULTRAOX 70	ULTRACOOL 2	CTA 20	ULTRASEC 8	500 L, 11 bar	200 L, 11 bar	270 L, 11 bar
ULTRAOX 90	ULTRACOOL 2	CTA 25	ULTRASEC 9	1,000 L, 11.5 bar	200 L, 11 bar	500 L, 11 bar
ULTRAOX 100	ULTRACOOL 3	CTA 25	ULTRASEC 11	1,000 L, 11.5 bar	270 L, 11 bar	500 L, 11 bar
ULTRAOX 120	ULTRACOOL 3	CTA 25	ULTRASEC 11	1,000 L, 11.5 bar	500 L, 11 bar	1,000 L, 11.5 bar
ULTRAOX 180	ULTRACOOL 4	CTA 25/1	ULTRASEC 13	1,000 L, 11.5 bar	500 L, 11 bar	1,000 L, 11.5 bar
ULTRAOX 260	ULTRACOOL 5	CTA 40	ULTRASEC 14	2,000 L, 11.5 bar	1,000 L, 11.5 bar	1,000 L, 11.5 bar
ULTRAOX 370	ULTRACOOL 6	CTA 40	ULTRASEC 25	2,000 L, 11.5 bar	1,000 L, 11.5 bar	1,000 L, 11.5 bar
ULTRAOX 440	ULTRACOOL 8	CTA 40/1	ULTRASEC 27	2 × 2,000 L, 11.5 bar	2,000 L, 11.5 bar	2,000 L, 11.5 bar
ULTRAOX 520	ULTRACOOL 8	CTA 40/1	ULTRASEC 27	2 × 2,000 L, 11.5 bar	2,000 L, 11.5 bar	2,000 L, 11.5 bar
ULTRAOX 560	ULTRACOOL 8	CTA 40/1	ULTRASEC 27	2 × 2,000 L, 11.5 bar	2,000 L, 11.5 bar	2,000 L, 11.5 bar
ULTRAOX 730	ULTRACOOL 9	CTA 50	ULTRASEC 28	3 × 2,000 L, 11.5 bar	2,000 L, 11.5 bar	2,000 L, 11.5 bar
ULTRAOX 820	ULTRACOOL 9	CTA 50/1	ULTRASEC 29	3 × 2,000 L, 11.5 bar	2,000 L, 11.5 bar	2,000 L, 11.5 bar
ULTRAOX 1120	ULTRACOOL 10	CTA 50/1	ULTRASEC 30	3 × 3,000 L, 11.5 bar	2,000 L, 11.5 bar	2,000 L, 11.5 bar
ULTRAOX 1640	ULTRACOOL 12	CTA 80	ULTRASEC 32	4 × 3,000 L, 11.5 bar	2,000 L, 11.5 bar	2 × 2,000 L, 11.5 bar

Tank pressures are max operating pressures. At 2,000 to 3,000 m, ULTRAOX 1640 uses 2 compressors, 2 oxygen filtration systems and 2 flow measurement systems.

ULTRACECO SC compressor data, 0 to 1,000 m

Model	Compressor	Quantity	Motor power kW	Working pressure bar
ULTRAOX 30	ULTRACECO SC 7-8	1	7.5	8
ULTRAOX 70	ULTRACECO SC 13-8	1	13	8
ULTRAOX 370	ULTRACECO SC 37-8Q	4	22.5	8

Compressor data for the other models on request.

Every angle.

2 photos of the ULTRAOX SC

ULTRAOX SC oxygen plant: compressor, cylinder rack, air treatment, tanks and ULTRACON generators

ULTRAOX SC plant laid out side by side, from receivers to the cylinder rack

Questions, answered.

Is ULTRAOX SC oil-free?

The air compressors are. ULTRAOX SC uses ULTRACECO SC oil-free scroll compressors. ULTRAOX ST uses ULTRASCREW oil lubricated screw compressors.

What purity does it deliver?

93% ± 3%, conforming to European Pharmacopoeia (Ph. Eur.) and United States Pharmacopeia (USP) specifications for medical oxygen.

What capacity range is available?

16 models, from 3.10 Nm³/h on ULTRAOX 30 to 165.3 Nm³/h on ULTRAOX 1640.

What happens if purity drops?

An alarm is raised at 90% purity. If purity falls below 90%, the oxygen flow is shut off and purged.

What are the air and oxygen pressures?

Air inlet > 7.5 bar and oxygen outlet 5 to 6 bar.

Four decades of engineering, backed end-to-end.

Certified quality management

ISO 13485:2016 (medical devices: quality management systems) and ISO 9001:2015 (quality management systems).

UltraCare support

Preventive and corrective maintenance, original spare parts and technical assistance 24 hours a day, 7 days a week.

Sized by our engineers

Tell us how the system will be used, and our engineering team sizes it and sends a quote.

Shipped from Portugal

Ultra Controlo plants are assembled and tested in our factories in Portugal, ready to be installed on site.
